EPOXY COALED CARBON STEEL DOUBLE WALL OIL WATER SEPARATOR (OWS) BY-PASS CLASS I

HOME PAGE| Products| Seperators| Oil Water Seperator| EPOXY COALED CARBON STEEL DOUBLE WALL OIL WATER SEPARATOR (OWS) BY-PASS CLASS I

Yerli Üretim

Stok Kodu: 6824

Bypass oil-water separator conforming to class I according to EN 858,

single and double walled tank made of carbon steel

is available in its structure. Inner and outer tank walls are epoxy coated

and integrated mud trap. Below the frost line

designed for underground installation. Rounded shape and

Its non-porous surface is resistant to oils and acids on interior and exterior surfaces.

resists, so easy and precise cleaning and disposal

is provided. Inlet and outlet connections with suitable flange connections

or pipe connections. Handles for crane transportation

is suitable for Automatically when it reaches its capacity

with 304 quality/316 quality stainless steel floating system

equipped. Washable koalens filters, small oil

fuses and holds the particles and provides more precise separation

is designed for The separator removes 10% of the initial flow

the remaining 90% through the bypass line to treated water.

passes through. The separator complies with load class EN 124 D400 (40 tons)

Includes cast iron access cover with sealed gasket. Discriminator

optionally oil level monitoring alarm device,

leak sensor, overflow sensor, vacuum leak detector and

sampling container.

CARBON STEEL

Fuel stations, Parking lots, Truck loading and unloading

fields, car dealerships, repair shops,

car washes, bus garages, military hangars and warehouses

facilities, fire stations, engine cleaning workshops,

vehicle recovery parking lots,

Airport apron, Train - Metro stations, Container

terminals, Industrial plants, risk of accidental oil spills

oil facilities.
